Chemical Resistant Silicone Coated Glass Fiber Fabric Abrasion Resistant 1040gsm

MOQ:	1000 pieces
Payment Terms:	T/T,PayPal,Xtransfer
Supply Ability:	50000 pieces per day

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Features:

Chemical Resistant, Flexible, Water And Oil Resistant

Features:

Chemical Resistant, Abrasion Resistant, Water Oil Resistant

Technique:

Silicone Coated

Processing Service:

Cutting, Punching

Shape:

Roll / Sheet

Application:

Industrial Gasket Pad, Seal, Cover

Weave Type:

Twill Woven

Yarn Type:

E-Glass

Thickness:

0.5mm (Customizable)

Unit Weight:

1040 G/m2 (Customizable)

Standing Temperature:

-70C To 280C

Thickness:

1.0mm (Customizable)

Packaging Details:

Wooden frame or cardboard box packaging, customizable

Highlight:

Chemical Resistant Fiberglass Cloth

Abrasion Resistant Silicone Fabric

Water Oil Resistant Cloth

Product Description

Silicone Coated Fiberglass Fabric Chemical Resistant Abrasion Resistant 1040gsm

Product Description

Silicone coated fiberglass fabric is a durable composite sheet formed from a twill woven glass fiber base and a silicone rubber coating. The combination gives a flexible, chemical resistant material with strong abrasion resistance.

Fiberglass base: woven from drawn molten glass filament for high strength, corrosion resistance, non flammability and stable dimensions under pressure and heat.

Silicone coating: the polysiloxane layer is bonded into the glass cloth, closing the weave and giving a smooth, non stick and skin friendly surface.

Process: high strength E-Glass fiberglass yarn is twill woven into a base cloth, then coated with silicone on both sides to form a dense weather resistant layer. The surface is level and flexible, easy to fold and cut, and does not delaminate or chalk after long term use. It will not spread flame on direct fire contact and effectively blocks high temperature radiation and heat conduction.

The fabric is chemical resistant, abrasion resistant and waterproof, with high mechanical strength and stable performance under heat.

Features

Chemical Resistance: withstands acids, alkalis, salts and many solvents for reliable industrial use.

Abrasion Resistant: the reinforced 1040gsm structure resists rubbing, scuffing and wear.

High Mechanical Strength: keeps warp 7000 N/5cm and weft 6000 N/5cm for strong puncture and tear resistance.

Temperature Stability: stable service from -70C to 280C for heated and cooled equipment.

Waterproof And Non Stick: the sealed silicone face repels water, oil and residues and cleans easily.

Electrical Insulation: good dielectric properties suit insulating liners and covers.

Fire Retardant: non flammable base and flame retardant coating for use near heat and sparks.

Customizable: weight, thickness, width, color and cut shapes can be produced to order.

Technical Parameters

ART NO		Silicone Coated Glass Fabric
WIDTH		1m
		Customizable
THICKNESS		1.0mm(Customizable)
COAT STYLE		SILICONE RUBBER(150g)
COAT THICKNESS		0.15mm
WEIGHT		1040g/㎡(Customizable)
TENSILE STRENGTH MIN	WARP	8000 N/5cm
	WEFT	7000 N/5cm
L.O.I%		<0.5%
SERVICE TEMPERATURE		280℃

Chemical Resistant Silicone Coated Glass Fiber Fabric Abrasion Resistant 1040gsm

FAQ

Q. 1: How long is the sample time ? Does the sample fee can be returned?

Proofing is usually 3-5 working days. If the order reach or exceed behind MOQ quantity, proofing fee refunded. If not reached behind MOQ quantity, proofing fee will be taken by you.
Q. 2: About the sample what is the cost of transportation?The freight depends on weight, packing size and your country or province region, etc.

You can confirm by photo and video to save this money, If you become our old customer.

Q. 3: How long can I expect to get the sample?

The samples will be ready for delivery in 3-5days. The samples will be sent via international express and would be arrived within 3-5 days.

Q. 4: Do you accept customized orders?

Yes, we do. Your customized orders are always welcomed. Please kindly offer us your samples or drawings, so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.

Q. 5: Can we have our Logo or company name to be printed on your products or package?

Sure. Your Logo could be printed on your products by Hot Stamping, Printing, Embossing, UV Coating, Silk-screen Printing or Sticker.

Q. 6: How to order?

Please send us your purchase order by Email or call us sales line

We need to know the following information for your order before sending you PI.

1) Product information-Quantity, Specification(Size, Material, Technological if needed and Packing requirements etc.)

2) Delivery time required.

3) Shipping information-Company name, Street address, Phone&Fax number, Destination sea port.

4) Forwarder's contact details if there's any in China.

Q. 7: How can order the products without any acknowledge of import ?

We could arrange you shipping or air or express for you and deliver everything to your port or provide you door to door service.

Q. 8: Do you have stock ?

We have a warehouse with a lot of stock, and most of the products are in normal production. If we have stock, we can deliver immediately.
