products details

Home Products

Silicone Coated Fiberglass Fabric Twill Woven Waterproof Heat Resistant 560gsm

MOQ:	1000 pieces
Payment Terms:	T/T,PayPal,Xtransfer
Supply Ability:	50000 pieces per day

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Features:

Fireproof, Water And Oil Resistant, Heat Insulation

Features:

Heat Resistant, Waterproof, Oil Resistant

Technique:

Silicone Coated

Processing Service:

Cutting

Shape:

Roll / Sheet

Application:

Heat Shield, Insulation Cover, Thermal Barrier

Weave Type:

Twill Woven

Yarn Type:

E-Glass

Thickness:

0.5mm (Customizable)

Unit Weight:

560 G/m2 (Customizable)

Standing Temperature:

-70C To 280C

Packaging Details:

Wooden frame or cardboard box packaging, customizable

Highlight:

Heat Resistant Silicone Cloth

Waterproof Fiberglass Fabric

Twill Woven Glass Cloth

Product Description

Silicone Coated Fiberglass Fabric Twill Woven Heat Resistant Waterproof 560gsm

Product Description

Silicone coated fiberglass fabric is a composite material built on a woven E-Glass fiberglass base and finished with a silicone rubber coating. It combines the mechanical strength of fiberglass with the heat and weather resistance of silicone.

Base cloth: woven from drawn molten glass filament, the fabric offers high tensile strength, chemical resistance and dimensional stability. A twill weave gives a smooth, drapeable surface that is easy to cut and fold.

Silicone coating: the polysiloxane coating is applied by dip coating and scraping so it bonds tightly to the glass cloth, sealing the surface and preventing the skin irritation common to bare fiberglass.

Process: high strength E-Glass fiberglass yarn is twill woven into a base cloth, then coated with silicone on both sides to form a dense weather resistant layer. The surface is level and flexible, easy to fold and cut, and does not delaminate or chalk after long term use. It will not spread flame on direct fire contact and effectively blocks high temperature radiation and heat conduction.

The finished sheet is heat resistant, waterproof and oil resistant, flexible and dimensionally stable, with good electrical insulation and a durable silicone surface.

Features

Heat And Weather Resistant: stable long term service from -70C to 280C with excellent thermal insulation and low heat conduction.

High Strength And Flexibility: keeps warp at least 7000 N/5cm and weft at least 6000 N/5cm yet stays soft to cut, fold and bend.

Waterproof And Oil Resistant: the sealed silicone surface repels water, oil and grease and is easy to wipe clean.

Chemical Resistance: resists common acids, alkalis and solvents.

Electrical Insulation: high dielectric strength and stable insulation performance.

Fire Retardant: non flammable glass base and flame retardant coating resist sparks and radiant heat.

Aging And Weather Resistance: resists ozone, UV and weather aging for a long service life.

Customizable: weight, thickness, width and color can be tailored to order.

Technical Parameters

ART NO		Silicone Coated Fiberglass Fabric
WIDTH		1m
		Customizable
THICKNESS		0.5mm(Customizable)
COAT STYLE		SILICONE RUBBER(80g)
COAT THICKNESS		0.08mm
WEIGHT		560g/㎡(Customizable)
TENSILE STRENGTH MIN	WARP	7000 N/5cm
	WEFT	6000 N/5cm
L.O.I%		<0.5%
SERVICE TEMPERATURE		280℃

Silicone Coated Fiberglass Fabric Twill Woven Waterproof Heat Resistant 560gsm

FAQ

Q. 1: How long is the sample time ? Does the sample fee can be returned?

Proofing is usually 3-5 working days. If the order reach or exceed behind MOQ quantity, proofing fee refunded. If not reached behind MOQ quantity, proofing fee will be taken by you.
Q. 2: About the sample what is the cost of transportation?The freight depends on weight, packing size and your country or province region, etc.

You can confirm by photo and video to save this money, If you become our old customer.

Q. 3: How long can I expect to get the sample?

The samples will be ready for delivery in 3-5days. The samples will be sent via international express and would be arrived within 3-5 days.

Q. 4: Do you accept customized orders?

Yes, we do. Your customized orders are always welcomed. Please kindly offer us your samples or drawings, so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.

Q. 5: Can we have our Logo or company name to be printed on your products or package?

Sure. Your Logo could be printed on your products by Hot Stamping, Printing, Embossing, UV Coating, Silk-screen Printing or Sticker.

Q. 6: How to order?

Please send us your purchase order by Email or call us sales line

We need to know the following information for your order before sending you PI.

1) Product information-Quantity, Specification(Size, Material, Technological if needed and Packing requirements etc.)

2) Delivery time required.

3) Shipping information-Company name, Street address, Phone&Fax number, Destination sea port.

4) Forwarder's contact details if there's any in China.

Q. 7: How can order the products without any acknowledge of import ?

We could arrange you shipping or air or express for you and deliver everything to your port or provide you door to door service.

Q. 8: Do you have stock ?

We have a warehouse with a lot of stock, and most of the products are in normal production. If we have stock, we can deliver immediately.
