| MOQ: | 1000 pieces |
| Payment Terms: | T/T, PayPal, Xtransfer |
| Supply Ability: | 50000 pieces per day |
Wholesale Price New Style Colorful Fiberglass Cloth Glass Fiber Fabric Cloth
Glass fiber cloth is a material woven from glass fibers, which has excellent properties such as high temperature resistance, corrosion resistance, thermal insulation, and insulation. Usually, alkali free glass fibers are melted into fibrous shapes at high temperatures, and then made through processes such as fiber stretching and weaving. Fiberglass cloth has strong mechanical strength and wear resistance, is not easy to age and corrode, and can work stably for a long time in high temperature environments. It is an ideal high-temperature insulation material.
Fiberglass cloth can be classified into various types based on its weaving and surface treatment methods, such as plain weave, twill weave, satin weave, etc. Among them, plain weave fabric has the characteristics of tight weaving and high strength, making it suitable for insulation applications with high requirements; Twill fabric has the characteristics of good flexibility and easy molding, and is suitable for some complex insulation occasions. There are also various surface treatment methods for fiberglass cloth, such as coating, impregnation, laminating, etc., which can enhance its waterproof, corrosion-resistant and other properties, improve its durability and service life.
| Parameter | Specification Range |
|---|---|
| Product Name | Colored / Dyed Fiberglass Fabric |
| Coloring Method | Pigment Coating (Acrylic-based) / Yarn Dyed / Surface Printing |
| Coating Type | Acrylic / Polyurethane / Silicone / Epoxy / Polyester |
| Glass Type | E-Glass / C-Glass / S-Glass / ECR-Glass |
| Weave Structure | Plain Weave / Twill Weave / Satin Weave / Lenor Weave |
| Base Fabric Weight (g/m²) | 80 – 600 g/m² |
| Finished Weight (g/m²) | 100 – 700 g/m² |
| Base Fabric Thickness (mm) | 0.08 – 0.80 mm |
| Finished Thickness (mm) | 0.10 – 1.00 mm |
| Width (cm/in) | 100cm / 127cm / 150cm / 200cm (39" / 50" / 59" / 79") |
| Standard Colors | Black / White / Red / Blue / Green / Yellow / Orange / Gray |
| Color Evenness | Uniform / Consistent across width |
| Coating Adhesion | Excellent – no peeling or flaking |
| Coating Flexibility | High – no cracking on bending |
| Dimensional Stability | ≤ 0.5% |
| Moisture Absorption | ≤ 1.0% |
| Application Methods for Color | Dip coating / Knife coating / Roll coating / Spray coating / Pad-dry-cure |
| Drying / Curing Temperature | 150°C – 200°C (302°F – 392°F) |
| Roll Length | 50m / 100m / 200m / Custom |
| Packaging | Core tube + PE film + Woven bag / Carton |
| Certifications |
ISO 9001 / RoHS / REACH / UL94 |
