Colored Fiberglass Cloth
Created with Pixso.

Thermal Fireproof Insulation Waterproof Fiberglass Cloth Alkali Free

Thermal Fireproof Insulation Waterproof Fiberglass Cloth Alkali Free

MOQ: 1000 pieces
Payment Terms: T/T, PayPal, Xtransfer
Supply Ability: 50000 pieces per day
Detail Information
Place of Origin:
Hebei, China
Certification:
ISO9001
Feature:
High Temperature Resistanrt
Yarn Type:
E-Glass
Color:
Customized
Alkali Content:
Alkali Free
Quality:
Flat,warp/weft Density Uniform
Processing Service:
Cutting
Good Features:
Reinforced Composite Materials
Width:
1M
Coating Adhesion:
Excellent – No Peeling Or Flaking
Packaging Details:
Wooden frame or cardboard box packaging, customizable
Highlight:

waterproof fiberglass cloth alkali free

,

fireproof fiberglass resin cloth

,

fireproof waterproof fiberglass cloth

Product Description

More Colors Thermal Fireproof Insulation Waterproof Fiberglass Cloth


Product Description



When choosing and using dyed fiberglass cloth, the following points should be noted:



1. Clearly define performance requirements. Firstly, it is necessary to clarify the specific requirements for the strength, weight, thickness, color fastness, weather resistance, flame retardancy, and other indicators of the material in the application scenario. There are differences in the performance of products produced by different formulas and processes.



2. Pay attention to material specifications. The warp and weft density, yarn count type, and weaving method (plain weave, diagonal weave, etc.) of fiberglass cloth directly affect its physical and mechanical properties. The weight per unit area (in grams) of acrylic coating affects its surface properties and composite performance.



3. Assess color fastness. Especially when used outdoors or in environments that may come into contact with light or friction, attention should be paid to the color's resistance to light and friction. This depends on the quality of the color paste used and the protective ability of the resin system.



4. Storage and processing conditions. Materials should be stored in a cool and dry place, avoiding heavy pressure. When cutting, sewing, or laminating composite materials, attention should be paid to environmental cleanliness to avoid contaminating the fabric surface. When compounding with other resins, it is recommended to conduct small sample tests first to confirm compatibility and bonding effect.





Features



Excellent physical properties: characterized by high strength, high modulus, low elongation, high tensile strength, good dimensional stability, and resistance to deformation.

High temperature resistance and flame retardancy: Glass fiber itself does not burn, and has excellent temperature resistance (usually able to withstand temperatures above 500 ℃, depending on the coating or post-treatment process), meeting strict fire safety standards.

Corrosion resistance and chemical stability: It has good resistance to chemicals such as acids, alkalis, and organic solvents, and is suitable for harsh environments.

Electrical insulation: With excellent dielectric properties, it is an ideal electrical insulation material.

Color persistence and aesthetics: Through specialized dyes or colorants, the colors are bright and strong, not easily faded, and meet decorative and identification needs.

Environmental Protection and Health: High quality products use non-toxic and odorless raw materials, comply with green building material standards, and are moisture-proof, mold proof, and insect bite proof.







Technical Parameters

Parameter Specification Range
Product Name Colored / Dyed Fiberglass Fabric
Coloring Method Pigment Coating (Acrylic-based) / Yarn Dyed / Surface Printing
Coating Type Acrylic / Polyurethane / Silicone / Epoxy / Polyester
Glass Type E-Glass / C-Glass / S-Glass / ECR-Glass
Weave Structure Plain Weave / Twill Weave / Satin Weave / Lenor Weave
Base Fabric Weight (g/m²) 80 – 600 g/m²
Color Evenness Uniform / Consistent across width
Coating Adhesion Excellent – no peeling or flaking
Coating Flexibility High – no cracking on bending
Opacity / Coverage Opaque – complete color coverage
Pigment Type Inorganic pigments / Organic pigments
Tensile Strength (Warp) ≥ 800 – 3500 N/50mm
Tensile Strength (Weft) ≥ 600 – 3000 N/50mm
Elongation at Break ≤ 3% – 5%
Chemical Resistance Resistant to: mild acids, alkalis, oils, grease
Abrasion Resistance Good – surface coating protects fibers
Weather Resistance Good for outdoor use (UV stabilized)
Dimensional Stability ≤ 0.5%
Moisture Absorption ≤ 1.0%
Application Methods for Color Dip coating / Knife coating / Roll coating / Spray coating / Pad-dry-cure
Packaging Core tube + PE film + Woven bag / Carton
Certifications

ISO 9001 / RoHS / REACH / UL94



Thermal Fireproof Insulation Waterproof Fiberglass Cloth Alkali Free Thermal Fireproof Insulation Waterproof Fiberglass Cloth Alkali Free



Thermal Fireproof Insulation Waterproof Fiberglass Cloth Alkali Free

Thermal Fireproof Insulation Waterproof Fiberglass Cloth Alkali Free



FAQ



Q. 1: How long is the sample time ? Does the sample fee can be returned?

Proofing is usually 3-5 working days. If the order reach or exceed behind MOQ quantity, proofing fee refunded. If not reached behind MOQ quantity, proofing fee will be taken by you.

Q. 2: About the sample what is the cost of transportation?
The freight depends on weight, packing size and your country or province region, etc.
You can confirm by photo and video to save this money, If you become our old customer.

Q. 3: How long can I expect to get the sample?
The samples will be ready for delivery in 3-5days. The samples will be sent via international express and would be arrived within 3-5 days.

Q. 4: Do you accept customized orders?
Yes, we do. Your customized orders are always welcomed. Please kindly offer us your samples or drawings, so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.

Q. 5: Can we have our Logo or company name to be printed on your products or package?
Sure. Your Logo could be printed on your products by Hot Stamping, Printing, Embossing, UV Coating, Silk-screen Printing or Sticker.

Q. 6: How to order?
Please send us your purchase order by Email or call us sales line
We need to know the following information for your order before sending you PI.
1) Product information-Quantity, Specification(Size, Material, Technological if needed and Packing requirements etc.)
2) Delivery time required.
3) Shipping information-Company name, Street address, Phone&Fax number, Destination sea port.
4) Forwarder's contact details if there's any in China.

Q. 7: How can order the products without any acknowledge of import ?
We could arrange you shipping or air or express for you and deliver everything to your port or provide you door to door service.

Q. 8: Do you have stock ?
We have a warehouse with a lot of stock, and most of the products are in normal production. If we have stock, we can deliver immediately.
