Insulation Resistant High Temperature Colored Glass Fiber Acrylic Coated Fiberglass Cloth For Welding Protection
Fiberglass cloth. Glass fiber is an inorganic non-metallic material made from glass as raw material, melted at high temperature and drawn. Its single filament diameter ranges from a few micrometers to over twenty micrometers, usually consisting of hundreds or even thousands of single filaments bundled into the original yarn, which is then made into a fabric shape through textile technology. Fiberglass cloth itself has characteristics such as non flammability, high temperature resistance, dimensional stability, and corrosion resistance. However, its surface is smooth, and its bonding strength with materials such as resin is limited. The original color is usually white or light yellow, and the color is relatively single.
Dyeing is not performed on the glass fiber itself, but rather by combining specific colorants or dyes with an acrylic resin coating system. During the processing, colored acrylic resin is uniformly adhered to the surface and gaps of the warp and weft yarns of the glass fiber cloth through immersion, scraping or spraying, and then cured at a certain temperature to crosslink the resin into a film, and the color is fixed accordingly. Related production focuses on process control to ensure the uniformity of color distribution and color fastness.
| Parameter | Specification Range |
|---|---|
| Product Name | Colored / Dyed Fiberglass Fabric |
| Coloring Method | Pigment Coating (Acrylic-based) / Yarn Dyed / Surface Printing |
| Coating Type | Acrylic / Polyurethane / Silicone / Epoxy / Polyester |
| Glass Type | E-Glass / C-Glass / S-Glass / ECR-Glass |
| Weave Structure | Plain Weave / Twill Weave / Satin Weave / Lenor Weave |
| Base Fabric Weight (g/m²) | 80 – 600 g/m² |
| Finished Weight (g/m²) | 100 – 700 g/m² |
| Base Fabric Thickness (mm) | 0.08 – 0.80 mm |
| Finished Thickness (mm) | 0.10 – 1.00 mm |
| Width (cm/in) | 100cm / 127cm / 150cm / 200cm (39" / 50" / 59" / 79") |
| Standard Colors | Black / White / Red / Blue / Green / Yellow / Orange / Gray |
| Color Evenness | Uniform / Consistent across width |
| Coating Adhesion | Excellent – no peeling or flaking |
| Coating Flexibility | High – no cracking on bending |
| Opacity / Coverage | Opaque – complete color coverage |
| Pigment Type | Inorganic pigments / Organic pigments |
| Tensile Strength (Warp) | ≥ 800 – 3500 N/50mm |
| Tensile Strength (Weft) | ≥ 600 – 3000 N/50mm |
| Elongation at Break | ≤ 3% – 5% |
| Temperature Resistance | 100°C – 180°C (212°F – 356°F) continuous Up to 200°C (392°F) intermittent |
| Flame Resistance | Self-extinguishing / Flame retardant |
| UV Resistance | High – UV stable pigments |
| Water Resistance | Water repellent / Waterproof |
