Colored Fiberglass Cloth
Created with Pixso.

Versatile Fireproof Colored Fiberglass Cloth Boat 600Gsm E Fiberglass Cloth Roll

Versatile Fireproof Colored Fiberglass Cloth Boat 600Gsm E Fiberglass Cloth Roll

MOQ: 1000 pieces
Payment Terms: T/T, PayPal, Xtransfer
Supply Ability: 50000 pieces per day
Detail Information
Place of Origin:
Hebei, China
Certification:
ISO9001
Feature:
High Temperature Resistanrt
Standing Temperature:
550℃
Yarn Type:
E-Glass
Application:
Wall/Roof Covering Cloth
Quality:
Flat,warp/weft Density Uniform
Processing Service:
Cutting
Good Features:
Reinforced Composite Materials
Width:
1M
Coating Adhesion:
Excellent – No Peeling Or Flaking
Packaging Details:
Wooden frame or cardboard box packaging, customizable
Highlight:

fireproof colored fiberglass cloth

,

colored fiberglass cloth boat

,

600gsm e fiberglass cloth

Product Description

Colorful Versatile Fireproof Fiberglass Fiberglass Boat 600Gsm Fiberglass Roll


Product Description



The color formation of alkali free glass fiber cloth is mainly related to the dyeing process during the production process. One way is to add different colored pigments to the glass raw material during the drawing stage of the glass fiber, and through high-temperature melting and drawing processes, make the glass fiber itself have different colors. The color formed in this way is relatively uniform and long-lasting because the pigment is integrated into the interior of the glass fiber.


Another way is to dye different colors onto the glass fiber cloth through printing and dyeing processes after weaving is completed. The printing and dyeing process can precisely control the distribution of colors and patterns, and can produce various complex patterns according to customer needs. However, the color of this method adheres to the surface of the fabric and may fade after multiple rubs or washes. In addition, the selection of pigments is also crucial, ensuring that they have good light resistance, temperature resistance, and chemical stability to ensure that alkali free glass fiber cloth can maintain bright and stable colors in different environments. In actual production, manufacturers will choose appropriate dyeing methods and pigments based on the product's purpose and customer requirements to achieve the desired color effect. At the same time, strict quality testing will be conducted to ensure that the uniformity and fastness of colors meet relevant standards.





Features



Excellent physical properties: characterized by high strength, high modulus, low elongation, high tensile strength, good dimensional stability, and resistance to deformation.

High temperature resistance and flame retardancy: Glass fiber itself does not burn, and has excellent temperature resistance (usually able to withstand temperatures above 500 ℃, depending on the coating or post-treatment process), meeting strict fire safety standards.

Corrosion resistance and chemical stability: It has good resistance to chemicals such as acids, alkalis, and organic solvents, and is suitable for harsh environments.

Electrical insulation: With excellent dielectric properties, it is an ideal electrical insulation material.

Color persistence and aesthetics: Through specialized dyes or colorants, the colors are bright and strong, not easily faded, and meet decorative and identification needs.

Environmental Protection and Health: High quality products use non-toxic and odorless raw materials, comply with green building material standards, and are moisture-proof, mold proof, and insect bite proof.







Technical Parameters

Parameter Specification Range
Product Name Colored / Dyed Fiberglass Fabric
Coloring Method Pigment Coating (Acrylic-based) / Yarn Dyed / Surface Printing
Coating Type Acrylic / Polyurethane / Silicone / Epoxy / Polyester
Glass Type E-Glass / C-Glass / S-Glass / ECR-Glass
Weave Structure Plain Weave / Twill Weave / Satin Weave / Lenor Weave
Base Fabric Weight (g/m²) 80 – 600 g/m²
Coating Adhesion Excellent – no peeling or flaking
Coating Flexibility High – no cracking on bending
Opacity / Coverage Opaque – complete color coverage
Pigment Type Inorganic pigments / Organic pigments
Tensile Strength (Warp) ≥ 800 – 3500 N/50mm
Tensile Strength (Weft) ≥ 600 – 3000 N/50mm
Elongation at Break ≤ 3% – 5%
Temperature Resistance 100°C – 180°C (212°F – 356°F) continuous
Up to 200°C (392°F) intermittent
Flame Resistance Self-extinguishing / Flame retardant
UV Resistance High – UV stable pigments
Water Resistance Water repellent / Waterproof
Chemical Resistance Resistant to: mild acids, alkalis, oils, grease
Abrasion Resistance Good – surface coating protects fibers
Weather Resistance Good for outdoor use (UV stabilized)
Packaging Core tube + PE film + Woven bag / Carton



Versatile Fireproof Colored Fiberglass Cloth Boat 600Gsm E Fiberglass Cloth Roll Versatile Fireproof Colored Fiberglass Cloth Boat 600Gsm E Fiberglass Cloth Roll



Versatile Fireproof Colored Fiberglass Cloth Boat 600Gsm E Fiberglass Cloth Roll

Versatile Fireproof Colored Fiberglass Cloth Boat 600Gsm E Fiberglass Cloth Roll
