| MOQ: | 1000 pieces |
| Payment Terms: | T/T, PayPal, Xtransfer |
| Supply Ability: | 50000 pieces per day |
Jacquard Braided Fiberglass Cloth Colour Glass Fibre Fabric Carbon Fiber Fabric
Acrylic resin coating is the key 'outerwear' that endows materials with ultimate properties. Acrylic resin is a synthetic polymer material known for its excellent weather resistance, transparency, adhesion, and flexibility. Liquid acrylic resin is uniformly adhered to the surface and fiber gaps of glass fiber cloth through processes such as impregnation, scraping, or spraying.
The process of adding stable colorants to resins or dyeing finished products. This enables the material to break through the limitations of traditional glass fiber products with monotonous colors, presenting rich and long-lasting colors, meeting the demands for aesthetics and identification functions in modern applications. Fiberglass cloth provides a sturdy skeleton, and acrylic resin solidifies to form a continuous protective and bonding layer, firmly locking in colors, resulting in a new type of material with vivid colors and composite properties.
| Parameter | Specification Range |
|---|---|
| Product Name | Colored / Dyed Fiberglass Fabric |
| Coloring Method | Pigment Coating (Acrylic-based) / Yarn Dyed / Surface Printing |
| Coating Type | Acrylic / Polyurethane / Silicone / Epoxy / Polyester |
| Glass Type | E-Glass / C-Glass / S-Glass / ECR-Glass |
| Weave Structure | Plain Weave / Twill Weave / Satin Weave / Lenor Weave |
| Base Fabric Weight (g/m²) | 80 – 600 g/m² |
| Finished Weight (g/m²) | 100 – 700 g/m² |
| Base Fabric Thickness (mm) | 0.08 – 0.80 mm |
| Opacity / Coverage | Opaque – complete color coverage |
| Pigment Type | Inorganic pigments / Organic pigments |
| Tensile Strength (Warp) | ≥ 800 – 3500 N/50mm |
| Tensile Strength (Weft) | ≥ 600 – 3000 N/50mm |
| Elongation at Break | ≤ 3% – 5% |
| Temperature Resistance | 100°C – 180°C (212°F – 356°F) continuous Up to 200°C (392°F) intermittent |
| Flame Resistance | Self-extinguishing / Flame retardant |
| UV Resistance | High – UV stable pigments |
| Water Resistance | Water repellent / Waterproof |
| Moisture Absorption | ≤ 1.0% |
| Roll Length | 50m / 100m / 200m / Custom |
| Packaging | Core tube + PE film + Woven bag / Carton |
| Certifications |
ISO 9001 / RoHS / REACH / UL94 |
Q. 1: How long is the sample time ? Does the sample fee can be returned?
