Alkali Free Dewaxed Heat Treated Fireproof Fiberglass Cloth Fire Cutting

Alkali Free Dewaxed Heat Treated Fireproof Fiberglass Cloth Fire Cutting

MOQ:	1000 pieces
Payment Terms:	T/T, PayPal, Xtransfer
Supply Ability:	50000 pieces per day

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Weave Type:

Twill Woven

Alkali Content:

Alkali Free

Feature:

High Temperature Resistanrt

Color:

Golden

Surface Energy:

High (after Heat Cleaning)

Technology:

Dewaxed/Desized

Surface Cleanliness:

High – No Organic Contamination

Flame Resistance:

Non-combustible / Self-extinguishing

Dimensional Stability:

≤ 0.5%

Packaging Details:

Wooden frame or cardboard box packaging, customizable

Highlight:

dewaxed fiberglass mesh cloth

dewaxed fireproof fiberglass cloth

alkali free fiberglass mesh cloth

Product Description

High Temperature Resistance Alkali Free Dewaxed/Heat Treated Fireproof Fiberglass Cloth Welding Blanket/Fire Cutting

Product Description

Dewaxed glass fiber cloth refers to glass fiber fabric that has undergone high-temperature heat treatment to remove protective sizing agents (wax or organic coatings) on the surface of glass fibers. This process aims to eliminate organic residues and significantly improve the wettability and adhesion between the base fabric and subsequent coatings such as resin. ‌‌
Appearance change: After dewaxing, the fabric surface usually changes from white to golden or light brown, with a softer hand feel than ordinary fiberglass fabric.
Performance improvement: Removing organic substances that hinder chemical bonding, significantly improving resin wettability, reducing fiber dust, and enhancing wear resistance.
The essence of the process is not to change the composition of the glass, but to evaporate the lubricating/protective agent added during weaving through high temperature (usually in an electric heating furnace), which belongs to the physical and chemical treatment process. ‌‌

Features

Excellent resin permeability: After removing wax, the fibers are exposed, allowing epoxy resin, silicone resin and other matrix materials to fully penetrate, significantly improving the dry and wet mechanical strength of the laminated board and avoiding delamination defects.

High temperature resistance and thermal stability: No organic wax residue, long-term use temperature can reach 300 ℃~500 ℃ (depending on the glass fiber model), instantaneous temperature resistance is higher, and no volatiles or carbonization are produced at high temperatures, with good dimensional stability.

High electrical insulation performance: no conductive impurities on the surface, stable dielectric performance, high breakdown voltage, suitable for high-frequency circuit substrates and high-voltage electrical insulation wrapping.

Clean and dust-free surface: After dewaxing and subsequent water washing treatment, the fabric surface is smooth, hairless, and stain free, reducing fiber dust and facilitating subsequent coating and laminating processes, resulting in a smoother appearance of the finished product. ‌‌

Color characteristics: After dewaxing treatment at 300 ℃~400 ℃, the finished product usually appears golden yellow or light brown, which is different from white or light yellow cloth that has not been dewaxed.

Chemical stability: retain the inherent acid and alkali resistance, corrosion resistance, non combustible characteristics of glass fiber, strong anti-aging ability, and long service life.

Processing adaptability: The texture is relatively soft (compared to untreated stiff fabric), easy to cut, sew, and punch, suitable for complex shape forming. ‌‌

Technical Parameters

Parameter	Specification Range
Product Name	Heat Cleaned Fiberglass Fabric
Process Type	Heat Cleaning / Thermal Desizing / Heat Treatment
Heat Treatment Temperature	350°C – 650°C (660°F – 1200°F)
Weave Structure	Plain Weave / Twill Weave / Satin Weave / Lenor Weave
Weight (g/m²)	50 – 900 g/m²
Thickness (mm)	0.05 – 1.2 mm
Width (cm/in)	80cm / 100cm / 127cm / 150cm / 200cm (31" / 39" / 50" / 59" / 79")
Residual Sizing Content	< 0.2% (typically < 0.1%)
Surface Cleanliness	High – no organic contamination
Surface Energy	High (after heat cleaning)
Elongation at Break	≤ 3% – 5%
Temperature Resistance (Substrate)	550°C – 800°C (1022°F – 1472°F)
Continuous Service Temperature	Up to 550°C (1022°F)
Resin Compatibility	Epoxy / Polyester / Vinyl Ester / Phenolic / Silicone / PTFE
Coating Compatibility	Silicone / PTFE / Acrylic / Polyurethane / Aluminum
Flame Resistance	Non-combustible / Self-extinguishing
Dimensional Stability	≤ 0.5%
Roll Length	50m / 100m / 200m / Custom
Packaging	Moisture-proof paper + Plastic film + Woven bag / Carton
Certifications	ISO 9001

Alkali Free Dewaxed Heat Treated Fireproof Fiberglass Cloth Fire Cutting
