Anti Oil Waterproof Fireproof Heat Insulating Cover Aluminum Foil Coated Fiberglass Cloth
Aluminum foil fiberglass cloth is a functional material composed of aluminum foil and fiberglass cloth, which combines the high reflectivity of aluminum foil with the high temperature resistance and tensile strength of fiberglass. It is widely used in fields such as insulation, thermal insulation, fire prevention, and electromagnetic shielding. Its core structure is a composite of aluminum foil layer and fiberglass cloth substrate through a special process. The aluminum foil layer is responsible for reflecting thermal radiation (with a reflectivity of over 90%), while the fiberglass cloth provides mechanical support and temperature resistance. It can usually withstand high temperature environments of 200 ℃ -600 ℃, depending on the grade of fiberglass cloth.
1. Aluminum foil fiberglass cloth is a material composed of aluminum foil and fiberglass cloth, which combines the reflective barrier properties of aluminum with the temperature resistance and high strength characteristics of fiberglass.
2. This material has practical applications in building insulation, industrial insulation, and thermal protection of transportation equipment, mainly utilizing its temperature resistance, reflection, barrier, and certain mechanical strength.
3. When selecting and using, attention should be paid to the specifications, quality, and adhesive properties of aluminum foil and fiberglass cloth, as well as safety and standardized operation during construction to ensure their effectiveness.
Excellent insulation and heat reflection: The aluminum foil layer has a reflectivity of over 90% for far-infrared thermal radiation, significantly reducing heat conduction and suitable for insulation and heat preservation scenarios.
High temperature resistance and flame retardancy: Glass fiber substrate can withstand temperatures up to -196 ℃ to 300 ℃ (some products can reach 500-600 ℃), complying with GB8624 A1 or DIN4102 A1 non combustible standards, and self extinguishing upon ignition.
High strength and flexibility are combined: the longitudinal and transverse tensile strength can reach 8000 × 6000 N/5cm, the texture is firm and not easy to tear, while maintaining a certain degree of flexibility for easy construction.
Good moisture resistance and sealing: The aluminum foil layer achieves near zero water vapor permeability, making it impermeable and non breathable, effectively blocking moisture and protecting the core material (such as rock wool and glass wool).
Strong corrosion resistance and weather resistance: treated with anti-corrosion coating or polyethylene hot air composite process, resistant to acid and alkali, mold and suitable for humid, industrial or outdoor environments.
Lightweight and easy to construct: The thickness is usually 0.25-3.0 mm, and the weight is 75-2000 g/m ². It can be cut and bonded, and is commonly used for air duct wrapping, pipeline insulation, equipment protection, etc.
| Parameter | Specification Range |
|---|---|
| Product Name | Fiberglass Aluminum Foil Fabric |
| Construction | Aluminum Foil + Fiberglass Fabric + Adhesive (lamination) |
| Aluminum Foil Thickness | 7μm – 25μm (0.00028" – 0.001") |
| Fiberglass Base Fabric Weight | 100 – 600 g/m² |
| Total Thickness | 0.15 – 1.0 mm |
| Total Weight | 150 – 800 g/m² |
| Temperature Resistance | -30°C to 150°C (-22°F to 300°F) continuous Up to 200°C (392°F) intermittent |
| Heat Reflectivity | ≥ 90% |
| Tensile Strength | ≥ 500 – 2000 N/50mm |
| Tear Strength | ≥ 50 – 200 N |
| Flame Resistance | UL94 V-0 / VW-1 |
| Moisture Resistance | Yes / Impermeable to water vapor |
| Peel Strength (Foil to Fabric) | ≥ 20 – 50 N/25mm |
| Roll Length | 25m / 50m / 100m / Custom |
| Standard Sizes (Pre-cut) | 1m x 1m / 1m x 5m / 1.2m x 10m / Custom |
