Aluminum Foil Cloth Fiberglass Composite Anti Radiation Thermal Blanket Fireproof Insulation

Aluminum Foil Cloth Fiberglass Composite Anti Radiation Thermal Blanket Fireproof Insulation

MOQ: 1000 pieces
Payment Terms: T/T, PayPal, Xtransfer
Supply Ability: 50000 pieces per day
Detail Information
Place of Origin:
Hebei, China
Certification:
ISO9001
Features:
Waterproof, Heat Resistant.anti-microbial
Name:
Aluminum Foil Fiberglass Fabric
Function:
Antioxidant And Thermal Insulation
Surface Treatment:
Aluminum Foil
Weave Type:
Plain, Twill,Satin
Usage:
As Facer Of PU And PIR Foam
Glass Type:
E-glass/ C-glass
Width:
1m/1.2m/1.5m/as Required
Color:
Silvery
Application:
Waterproof, Heat Resistant.anti-microbial
Packaging Details:
Wooden frame or cardboard box packaging, customizable
Highlight:

Aluminum Foil Cloth Fiberglass

,

Anti Radiation aluminum foil fiberglass

,

Fireproof aluminum foil fiber glass cloth

Product Description

Aluminum Foil Cloth Fiberglass Composite Anti-Radiation Thermal Blanket Fireproof Insulation


Product Description



Aluminum foil fiberglass cloth is used in multiple industries. In the field of architecture, it is often used as an insulation material. For example, when laid in roof or wall structures, the aluminum foil layer can reflect solar radiation heat, reducing the transfer of heat to the interior, while the glass fiber cloth layer provides a certain insulation effect, helping to regulate indoor temperature. In the industrial field, it can be used for external insulation of pipelines, storage tanks, and other equipment, playing a role in protecting internal insulation materials, preventing moisture, and reflecting heat. In the field of transportation, such as inside cars, this material is sometimes used to isolate the heat in the engine compartment or for insulation and protection of certain components. Aluminum foil fiberglass cloth can also play a certain role in specific situations that require thermal or electromagnetic shielding.



When choosing aluminum foil fiberglass cloth, several factors need to be considered. Firstly, the thickness and purity of the aluminum foil directly affect its reflection and barrier effects. Secondly, the weight and weaving density of glass fiber cloth are related to the overall strength and durability of the material. Furthermore, the quality of the adhesive determines the firmness of the bonding between aluminum foil and fiberglass cloth, as well as whether it will delaminate or release harmful substances in high temperature environments. Finally, the specifications and dimensions of the product need to be tailored or selected with the appropriate width according to the actual application scenario.





Features



Excellent insulation and heat reflection: The aluminum foil layer has a reflectivity of over 90% for far-infrared thermal radiation, significantly reducing heat conduction and suitable for insulation and heat preservation scenarios.


High temperature resistance and flame retardancy: Glass fiber substrate can withstand temperatures up to -196 ℃ to 300 ℃ (some products can reach 500-600 ℃), complying with GB8624 A1 or DIN4102 A1 non combustible standards, and self extinguishing upon ignition.


High strength and flexibility are combined: the longitudinal and transverse tensile strength can reach 8000 × 6000 N/5cm, the texture is firm and not easy to tear, while maintaining a certain degree of flexibility for easy construction.


Good moisture resistance and sealing: The aluminum foil layer achieves near zero water vapor permeability, making it impermeable and non breathable, effectively blocking moisture and protecting the core material (such as rock wool and glass wool).


Strong corrosion resistance and weather resistance: treated with anti-corrosion coating or polyethylene hot air composite process, resistant to acid and alkali, mold and suitable for humid, industrial or outdoor environments.


Lightweight and easy to construct: The thickness is usually 0.25-3.0 mm, and the weight is 75-2000 g/m ². It can be cut and bonded, and is commonly used for air duct wrapping, pipeline insulation, equipment protection, etc.







Technical Parameters

Parameter Specification Range
Construction Aluminum Foil + Fiberglass Fabric + Adhesive (lamination)
Aluminum Foil Thickness 7μm – 25μm (0.00028" – 0.001")
Fiberglass Base Fabric Weight 100 – 600 g/m²
Total Thickness 0.15 – 1.0 mm
Total Weight 150 – 800 g/m²
Width 100cm / 120cm / 150cm (39" / 47" / 59")
Heat Reflectivity ≥ 90%
Tensile Strength ≥ 500 – 2000 N/50mm
Tear Strength ≥ 50 – 200 N
Flame Resistance UL94 V-0 / VW-1
Moisture Resistance Yes / Impermeable to water vapor
Chemical Resistance Resistant to: oil, grease, mild acids/alkalis
Roll Length 25m / 50m / 100m / Custom
Standard Sizes (Pre-cut) 1m x 1m / 1m x 5m / 1.2m x 10m / Custom
Packaging Core tube + PE film + Carton / Pallet

Aluminum Foil Cloth Fiberglass Composite Anti Radiation Thermal Blanket Fireproof Insulation Aluminum Foil Cloth Fiberglass Composite Anti Radiation Thermal Blanket Fireproof Insulation





Aluminum Foil Cloth Fiberglass Composite Anti Radiation Thermal Blanket Fireproof Insulation

Aluminum Foil Cloth Fiberglass Composite Anti Radiation Thermal Blanket Fireproof Insulation
