Stainless Steel Wire Reinforced Silicone Fiberglass Fabric For Fire Curtain

Stainless Steel Wire Reinforced Silicone Fiberglass Fabric For Fire Curtain

Product Description

Fiberglass steel wire cloth is a mesh or cloth like material composed of glass fibers and metal steel wires composite through a specific process. It is not simply a physical mixture, but fully utilizes the advantages of two basic materials to achieve complementary and enhanced performance.

*Fiberglass section: usually refers to extremely fine fibers made by pulling molten glass. It has the advantages of light weight, high strength (especially tensile strength), non flammability, corrosion resistance, good insulation, and dimensional stability. But its texture is relatively brittle, and its shear and impact resistance are relatively weak.

*Steel wire section: usually refers to low-carbon steel wire or stainless steel wire that has undergone drawing treatment. It endows the material with excellent tensile strength, toughness, impact resistance, and dimensional retention ability, but it is relatively heavy and poses a risk of corrosion in certain environments.

After combining the two, glass fiber steel wire cloth not only inherits the lightweight, corrosion-resistant, and insulating properties of glass fiber, but also incorporates the toughness and high strength of steel wire, forming a more balanced and powerful composite material.

Features

1. High strength and high modulus: Combining the high tensile strength of glass fiber and the support toughness of steel wire, the finished fabric has high mechanical strength and modulus, which can withstand large loads without deformation or fracture.

2. Good dimensional stability: The material is less affected by temperature and humidity changes, has a low coefficient of thermal expansion, and can maintain long-term stability in shape and size. It is suitable for occasions that require dimensional accuracy.

3. Excellent corrosion resistance: Glass fiber itself has good resistance to most chemicals such as acids, alkalis, and salts, which makes composite materials stable in most corrosive environments (non strong hydrofluoric acid or strong alkali long-term effects) and have a long service life. If stainless steel wire is used, the corrosion resistance is better.

4. Impact resistance and fatigue resistance: The addition of steel wire significantly improves the brittleness of pure glass fiber materials, enhancing their ability to resist dynamic impact and repeated loads (fatigue resistance).

5. Non flammability and insulation: Glass fiber is an inorganic material that does not burn and can have a flame retardant effect. It has good electrical insulation performance.

6. Design and adaptability: By adjusting the thickness and weaving density of glass fibers, the diameter and material of steel wires (such as galvanized and stainless steel), as well as the mesh size and weaving structure (plain weave, diagonal weave, etc.), products that meet different strength, flexibility, aperture, and weather resistance requirements can be produced.
