Flameproof Plain Weave Heat Treated Fiberglass Fabric Welding Fire Blanket

Flameproof Plain Weave Heat Treated Fiberglass Fabric Welding Fire Blanket

MOQ:	1000 pieces
Payment Terms:	T/T, PayPal, Xtransfer
Supply Ability:	50000 pieces per day

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Alkali Content:

Alkali Free

Material:

100% Fiberglass

Feature:

High Temperature Resistanrt

Standing Temperature:

550℃

Color:

Golden

Surface Energy:

High (after Heat Cleaning)

Technology:

Dewaxed/Desized

Surface Cleanliness:

High – No Organic Contamination

Dimensional Stability:

≤ 0.5%

Packaging Details:

Wooden frame or cardboard box packaging, customizable

Highlight:

flameproof fireproof fiberglass fabric

flameproof heat treated fiberglass fabric

plain weave fireproof fiberglass fabric

Product Description

Flameproof Fabric Fiberglass Plain Weave Heat Treated Glass Fibre Fabric Welding Fire Blanket

Product Description

Glass fiber fabric is woven by cost-effective fiberglass texturized yarn or filament fiberglass yarn. Plain, twill, satin woven glass fabric are typical woven patterns. Fiberglass cloth are used to tailor all kind of flame retardant elements, insulating, able to withstand high temperatures and maintain their mechanical resistance keeping their flexibility and lightness.

These fabrics are composed by continuous filaments in order to raise their pulling resistance and their superficial softness, either they could be customized to raise their thermal insulating capacities. In normal conditions, they offer a continuous thermal resistance up to 550ºC. They are very used as the core of textile constructions for high temperatures due to their good mechanical qualities. This fiberglass insulation fabric is specially designed for heat resistance, fireproof and basis woven fabric for coating and aluminum foil.

We offers high quality and cheap fiberglass cloth 430g/m2, 620g/m2, 840g/m2, 1000g/m2, style 3732 (TG430), 3784, etc. There are available with wire (Stainless steel wire, copper wire) insert glass fabric and caramelized finish (Desized/Heat treatment) glass fabric.

Features

Excellent resin permeability: After removing wax, the fibers are exposed, allowing epoxy resin, silicone resin and other matrix materials to fully penetrate, significantly improving the dry and wet mechanical strength of the laminated board and avoiding delamination defects.

High temperature resistance and thermal stability: No organic wax residue, long-term use temperature can reach 300 ℃~500 ℃ (depending on the glass fiber model), instantaneous temperature resistance is higher, and no volatiles or carbonization are produced at high temperatures, with good dimensional stability.

High electrical insulation performance: no conductive impurities on the surface, stable dielectric performance, high breakdown voltage, suitable for high-frequency circuit substrates and high-voltage electrical insulation wrapping.

Clean and dust-free surface: After dewaxing and subsequent water washing treatment, the fabric surface is smooth, hairless, and stain free, reducing fiber dust and facilitating subsequent coating and laminating processes, resulting in a smoother appearance of the finished product. ‌‌

Color characteristics: After dewaxing treatment at 300 ℃~400 ℃, the finished product usually appears golden yellow or light brown, which is different from white or light yellow cloth that has not been dewaxed.

Chemical stability: retain the inherent acid and alkali resistance, corrosion resistance, non combustible characteristics of glass fiber, strong anti-aging ability, and long service life.

Processing adaptability: The texture is relatively soft (compared to untreated stiff fabric), easy to cut, sew, and punch, suitable for complex shape forming. ‌‌

Technical Parameters

Parameter	Specification Range
Product Name	Heat Cleaned Fiberglass Fabric
Process Type	Heat Cleaning / Thermal Desizing / Heat Treatment
Heat Treatment Temperature	350°C – 650°C (660°F – 1200°F)
Weave Structure	Plain Weave / Twill Weave / Satin Weave / Lenor Weave
Weight (g/m²)	50 – 900 g/m²
Thickness (mm)	0.05 – 1.2 mm
Contact Angle (Water)	< 10° (after heat cleaning)
Tensile Strength (Warp) – Before	≥ 800 – 4000 N/50mm
Tensile Strength (Warp) – After	≥ 600 – 3500 N/50mm
Tensile Strength (Weft) – Before	≥ 600 – 3500 N/50mm
Continuous Service Temperature	Up to 550°C (1022°F)
Resin Compatibility	Epoxy / Polyester / Vinyl Ester / Phenolic / Silicone / PTFE
Coating Compatibility	Silicone / PTFE / Acrylic / Polyurethane / Aluminum
Flame Resistance	Non-combustible / Self-extinguishing
Moisture Absorption	≤ 0.5%
Quality Control	LOI test / Tensile test / Thickness check / Visual inspection
Roll Length	50m / 100m / 200m / Custom
Packaging	Moisture-proof paper + Plastic film + Woven bag / Carton
Certifications	ISO 9001

Flameproof Plain Weave Heat Treated Fiberglass Fabric Welding Fire Blanket

FAQ

Q. 1: How long is the sample time ? Does the sample fee can be returned?

Proofing is usually 3-5 working days. If the order reach or exceed behind MOQ quantity, proofing fee refunded. If not reached behind MOQ quantity, proofing fee will be taken by you.
Q. 2: About the sample what is the cost of transportation?The freight depends on weight, packing size and your country or province region, etc.

You can confirm by photo and video to save this money, If you become our old customer.

Q. 3: How long can I expect to get the sample?

The samples will be ready for delivery in 3-5days. The samples will be sent via international express and would be arrived within 3-5 days.

Q. 4: Do you accept customized orders?

Yes, we do. Your customized orders are always welcomed. Please kindly offer us your samples or drawings, so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.

Q. 5: Can we have our Logo or company name to be printed on your products or package?

Sure. Your Logo could be printed on your products by Hot Stamping, Printing, Embossing, UV Coating, Silk-screen Printing or Sticker.

Q. 6: How to order?

Please send us your purchase order by Email or call us sales line

We need to know the following information for your order before sending you PI.

1) Product information-Quantity, Specification(Size, Material, Technological if needed and Packing requirements etc.)

2) Delivery time required.

3) Shipping information-Company name, Street address, Phone&Fax number, Destination sea port.

4) Forwarder's contact details if there's any in China.

Q. 7: How can order the products without any acknowledge of import ?

We could arrange you shipping or air or express for you and deliver everything to your port or provide you door to door service.

Q. 8: Do you have stock ?

We have a warehouse with a lot of stock, and most of the products are in normal production. If we have stock, we can deliver immediately.
