Industrial Grade E-Glass Alkali Free Dewaxed Heat Treated Fiberglass Fabric For Welding Blankets

Industrial Grade E-Glass Alkali Free Dewaxed Heat Treated Fiberglass Fabric For Welding Blankets

MOQ:	1000 pieces
Payment Terms:	T/T, PayPal, Xtransfer
Supply Ability:	50000 pieces per day

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Application:

High Temperature Insulation

Alkali Content:

Alkali Free

Weave Type:

Twill Woven

Material:

100% Fiberglass

Feature:

High Temperature Resistanrt

Standing Temperature:

550℃

Yarn Type:

E-Glass

Raw Material:

Fiber Glass Roving

Color:

Golden

Technology:

Dewaxed/Desized

Packaging Details:

Wooden frame or cardboard box packaging, customizable

Highlight:

dewaxed heat treated fiberglass fabric

industrial fireproof fiberglass fabric

industrial heat treated fiberglass fabric

Product Description

Industrial-Grade E-Glass Alkali-Free Dewaxed Fiberglass Cloth Various Thickness For Fire Retardant Welding Blankets

Product Description

Dewaxed glass fiber cloth is a high-performance glass fiber fabric that has undergone special high-temperature or chemical treatment to remove surface paraffin type wetting agents (sizing agents). It is a key foundational material in the fields of composite material manufacturing, electronics industry, and high-end insulation.

Ordinary glass fibers are coated with a layer of "wetting agent" during the drawing process, mainly composed of paraffin, coupling agent, and film-forming agent, aimed at protecting the fibers, reducing wear, and facilitating textile processing. However, this layer of organic matter can hinder the direct bonding between resin or other matrix materials and glass fibers.

The dewaxing process is the process of removing these organic components through specific means:

Heat treatment method: Send the fiberglass cloth into a continuous dewaxing furnace, and at a high temperature of 300 ℃~400 ℃, completely melt and evaporate the paraffin type surface pre-treatment agent, making the fibers become exposed inorganic state.

Chemical treatment method: Some processes are supplemented with acid leaching (such as using 1.5-3.5 mol/L hydrochloric acid) and water washing to thoroughly remove residual impurities, ensuring that the fiber surface is clean and highly active.

Features

Excellent resin permeability: After removing wax, the fibers are exposed, allowing epoxy resin, silicone resin and other matrix materials to fully penetrate, significantly improving the dry and wet mechanical strength of the laminated board and avoiding delamination defects.

High temperature resistance and thermal stability: No organic wax residue, long-term use temperature can reach 300 ℃~500 ℃ (depending on the glass fiber model), instantaneous temperature resistance is higher, and no volatiles or carbonization are produced at high temperatures, with good dimensional stability.

High electrical insulation performance: no conductive impurities on the surface, stable dielectric performance, high breakdown voltage, suitable for high-frequency circuit substrates and high-voltage electrical insulation wrapping.

Clean and dust-free surface: After dewaxing and subsequent water washing treatment, the fabric surface is smooth, hairless, and stain free, reducing fiber dust and facilitating subsequent coating and laminating processes, resulting in a smoother appearance of the finished product. ‌‌

Color characteristics: After dewaxing treatment at 300 ℃~400 ℃, the finished product usually appears golden yellow or light brown, which is different from white or light yellow cloth that has not been dewaxed.

Chemical stability: retain the inherent acid and alkali resistance, corrosion resistance, non combustible characteristics of glass fiber, strong anti-aging ability, and long service life.

Processing adaptability: The texture is relatively soft (compared to untreated stiff fabric), easy to cut, sew, and punch, suitable for complex shape forming. ‌‌

Technical Parameters

Parameter	Specification Range
Product Name	Fiberglass Aluminum Foil Fabric
Construction	Aluminum Foil + Fiberglass Fabric + Adhesive (lamination)
Aluminum Foil Thickness	7μm – 25μm (0.00028" – 0.001")
Fiberglass Base Fabric Weight	100 – 600 g/m²
Total Thickness	0.15 – 1.0 mm
Total Weight	150 – 800 g/m²
Width	100cm / 120cm / 150cm (39" / 47" / 59")
Color	Aluminum
Temperature Resistance	-30°C to 150°C (-22°F to 300°F) continuous Up to 200°C (392°F) intermittent
Heat Reflectivity	≥ 90%
Tensile Strength	≥ 500 – 2000 N/50mm
Tear Strength	≥ 50 – 200 N
Flame Resistance	UL94 V-0 / VW-1
Moisture Resistance	Yes / Impermeable to water vapor
Chemical Resistance	Resistant to: oil, grease, mild acids/alkalis
Adhesive Type	Acrylic / Silicone / Pressure Sensitive (PSA)
Peel Strength (Foil to Fabric)	≥ 20 – 50 N/25mm
Roll Length	25m / 50m / 100m / Custom
Standard Sizes (Pre-cut)	1m x 1m / 1m x 5m / 1.2m x 10m / Custom
Packaging	Core tube + PE film + Carton / Pallet

Industrial Grade E-Glass Alkali Free Dewaxed Heat Treated Fiberglass Fabric For Welding Blankets

FAQ

Q. 1: How long is the sample time ? Does the sample fee can be returned?

Proofing is usually 3-5 working days. If the order reach or exceed behind MOQ quantity, proofing fee refunded. If not reached behind MOQ quantity, proofing fee will be taken by you.
Q. 2: About the sample what is the cost of transportation?The freight depends on weight, packing size and your country or province region, etc.

You can confirm by photo and video to save this money, If you become our old customer.

Q. 3: How long can I expect to get the sample?

The samples will be ready for delivery in 3-5days. The samples will be sent via international express and would be arrived within 3-5 days.

Q. 4: Do you accept customized orders?

Yes, we do. Your customized orders are always welcomed. Please kindly offer us your samples or drawings, so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.

Q. 5: Can we have our Logo or company name to be printed on your products or package?

Sure. Your Logo could be printed on your products by Hot Stamping, Printing, Embossing, UV Coating, Silk-screen Printing or Sticker.

Q. 6: How to order?

Please send us your purchase order by Email or call us sales line

We need to know the following information for your order before sending you PI.

1) Product information-Quantity, Specification(Size, Material, Technological if needed and Packing requirements etc.)

2) Delivery time required.

3) Shipping information-Company name, Street address, Phone&Fax number, Destination sea port.

4) Forwarder's contact details if there's any in China.

Q. 7: How can order the products without any acknowledge of import ?

We could arrange you shipping or air or express for you and deliver everything to your port or provide you door to door service.

Q. 8: Do you have stock ?

We have a warehouse with a lot of stock, and most of the products are in normal production. If we have stock, we can deliver immediately.
