Prefabricated Interior Wall Panels Lightweight Autoclaved Aerated Concrete Aac Block For Building Construction

MOQ:	1000 pieces
Payment Terms:	T/T, PayPal, Xtransfer
Supply Ability:	50000 pieces per day

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei, China

Certification:

ISO9001

Porosity:

Solid

Usae:

Wall, Partition, Floor, Roof,

Function:

Acid Resistance Bricks

Compressive Strength:

3.5/5.0 MPa

Size/Dimensions:

Customized

Process:

Mix Raw Material, Modular Panel,cutting And Steam Curing

Raw Material:

Silica Sand, Cement, Lime

Thermal Conductivity:

<=0.14 Dry (w/m.k)

Fire Resistance:

Up To 4 Hours

Packaging Details:

Wooden frame or cardboard box packaging, customizable

Highlight:

lightweight autoclaved aerated concrete aac block

prefabricated autoclaved aerated concrete aac block

prefabricated autoclaved aerated concrete blocks aac blocks

Product Description

Prefabricated Interior Wall Panels Lightweight AAC Panel Autoclaved Aerated Concrete Blocks For Building Construction

Product Description

AAC is available in blocks of various sizes, or more commonly, as reinforced panels sold as part of a complete building system that includes floor and roof panels, and interior and exterior walls.

Wall panels are storey height, reinforced and mechanically fixed. AAC can also be used in panel form for floor and roof construction. AAC blocks are made to very exacting dimensions and are usually laid in thin-bed mortar that is applied with a toothed trowel, although more conventional thick-bed mortar can be used.

All structural design should be prepared by a competent person, and may require preparation and approval by a qualified engineer. The AAC manufacturer can provide detailed technical advice that, when followed, should help to ensure successful use of the product.

The higher resource efficiency of autoclaved aerated concrete allows AAC to have a lower environmental impact than conventional concrete, from raw material processing to the disposal of aerated concrete waste. The production of aerated concrete blocks requires relatively little raw materials per cubic meter of product and material cost can be as low as a fifth of the production of other building materials.

Features

Autoclaved aerated concrete (AAC) is concrete that has been manufactured to contain closed air pockets. AAC is one-fifth the weight of concrete.

AAC is available as panels and blocks. AAC wall panels are typically used for cladding, but can also be loadbearing. AAC floor and roof panels are also available.

AAC blocks can be used for loadbearing structures up to 3 storeys, and AAC panels can be used for cladding.

AAC has medium thermal mass and provides very good thermal insulation.

AAC is relatively easy to work with but can also be easily damaged. Specific construction techniques are required.

AAC used externally should be coated with a vapour-permeable, water-resistant finish. Render to blockwork must be a proprietary mix compatible with the AAC substrate.

Technical Parameters

Parameter	Specification Range
Product Name	Autoclaved Aerated Concrete Blocks
Raw Materials	Silica sand, cement, lime, gypsum, aluminum powder, water
Curing Process	Autoclaved – high temperature & high pressure steam curing
Density Grade	B04 / B05 / B06 / B07
Oven Dry Density (kg/m³)	B04: ≤400 B05: ≤500 B06: ≤600 B07: ≤700
Strength Grade	A2.5 / A3.5 / A5.0 / A7.5
Thermal Conductivity (W/m·K)	B04: ≤0.09 B05: ≤0.11 B06: ≤0.13 B07: ≤0.15
Drying Shrinkage (mm/m)	Standard method: ≤0.30 Rapid method: ≤0.50
Water Absorption	≤ 210 gm/dm³
Fire Resistance	2 – 8 hours (depending on thickness)
Fire Resistance by Thickness	100mm: 3.75 hr 150mm: 5.75 hr 200mm: 8.00 hr
Sound Insulation (dB)	100mm: 38 dB 150mm: 40 dB 200mm: 42 dB
Poisson's Ratio	0.2
Applications	Load-bearing walls / Non-load-bearing walls / Interior & exterior walls / Infill walls / Fire-rated partitions / Thermal insulation layers

Prefabricated Interior Wall Panels Lightweight Autoclaved Aerated Concrete Aac Block For Building Construction

FAQ

Q. 1: How long is the sample time ? Does the sample fee can be returned?

Proofing is usually 3-5 working days. If the order reach or exceed behind MOQ quantity, proofing fee refunded. If not reached behind MOQ quantity, proofing fee will be taken by you.
Q. 2: About the sample what is the cost of transportation?The freight depends on weight, packing size and your country or province region, etc.

You can confirm by photo and video to save this money, If you become our old customer.

Q. 3: How long can I expect to get the sample?

The samples will be ready for delivery in 3-5days. The samples will be sent via international express and would be arrived within 3-5 days.

Q. 4: Do you accept customized orders?

Yes, we do. Your customized orders are always welcomed. Please kindly offer us your samples or drawings, so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.

Q. 5: Can we have our Logo or company name to be printed on your products or package?

Sure. Your Logo could be printed on your products by Hot Stamping, Printing, Embossing, UV Coating, Silk-screen Printing or Sticker.

Q. 6: How to order?

Please send us your purchase order by Email or call us sales line

We need to know the following information for your order before sending you PI.

1) Product information-Quantity, Specification(Size, Material, Technological if needed and Packing requirements etc.)

2) Delivery time required.

3) Shipping information-Company name, Street address, Phone&Fax number, Destination sea port.

4) Forwarder's contact details if there's any in China.

Q. 7: How can order the products without any acknowledge of import ?

We could arrange you shipping or air or express for you and deliver everything to your port or provide you door to door service.

Q. 8: Do you have stock ?

We have a warehouse with a lot of stock, and most of the products are in normal production. If we have stock, we can deliver immediately.
